YS-RH14-10-W : 10 Kg payload welding robots

  • After-sales Service:

    Video Technical Support, Online Support

  • Warranty:

    1 Year

  • Control Mode:

    Continuous Path Control

  • Drive Mode:

    Electric

  • Application:

    Welding

  • Condition:

    New

  • Customization:

    Available

Lorem ipsum dolor sit amet, consectetur adipisicing elit. Officiis velit libero vero, aliquid magnam sed, quidem labore unde aspernatur esse iusto quo quas, dolorum atque dignissimos asperiores. Ab, est accusantium

Contact Now
Aryan Sisodiya
Mr. Aryan Sisodiya
Contact Now

Product Description

Payload: 10 KG
Stroke: 1440 MM
Repeatability: ± 0.08 MM
Robot Detail
Model No.YS-RH14-10-W
Controlled Axis6 - DOF
Max Payload10 Kg
Max Stroke1440 MM
IP LevelJ1, J2-IP 56 & J3, J4, J5, J6-IP 67
Installation ModeFloor Type / Ceiling Type
Robot Mass170 Kg
Repeatability± 0.08 MM
Travel Range & Travel Speed
J1 Axis S±167 deg & 169 deg/s
J2 Axis L+0-175 deg & 169 deg/s
J3 Axis U-80 deg -150 deg & 169 deg/s
J4 Axis R±190 deg & 280 deg/s
J5 Axis B-105 deg - +130 deg & 240 deg/s
J6 Axis T±210 deg & 520 deg/s
Welding System Details
Welding MachineStandard - Megmeet ehave cm 350 AR
Optional - Megmeet Artsen & Artsen Plus
Welding Current350 AMP / 500 AMP
Welding TorchStandard air cooling torch with built-in anti collision protection
Electrical Cabinet Specification
Dimension785*550*435MM
Cabinet Mass60 Kg
Cooling MethodNatural Cooling
IP LevelIP 54
Input Power3 HP 380 VAC 50/60 HZ
Transformer30. KVA (380 V to 220 V Isolated Transformer)
I/O SignalDigital Input/output ; 2 Analog Output 0-10 V
LANMODBUS TCP/IP
Installation Environment
Ambient Temperature0-45 deg
Humidity20-80% RH, No Condensing
VibrationBelow 0.5 g
AltitudeBelow 1000 M
Other RequirementWith No Corrosive or Combustible Gas
With No Water, Oil & Drug Splashing
With No Electromagnetic Field Nearby
With No Radiations Nearby
